New Block Casting 350CI Crate Engine | Longblock | Aluminum Heads | Roller Cam | Fuel Injected | Deluxe Dressed w/ Pulleys - Black

$7,589.00

This engine will be dyno tested before it ships to you at no additional charge (others charge $500)!
Part #: BP3505CTFK

Description:

Dyno Tested Warranty
  • HP & Torque: 390 HP / 410 FT LBS
  • Compression Ratio: 9.2:1
  • Aluminum Heads
  • Hydraulic Roller Cam
  • Cast Iron Crankshaft
  • Hypereutectic Pistons

Block:

  • NEW BluePrint Cast Iron Block
  • Manufactured and Machined in the USA!
  • 4-Bolt Main
  • 4.000" Bore
  • 1-Piece Rear Main Seal
  • Mech fuel pump provision: Yes
  • Passenger Side Dipstick
  • Drilled and tapped for clutch linkage

Rotating Assembly:

  • Cast Iron Crankshaft
  • 3.480" Stroke
  • Forged 5.700" connecting rods
  • Hypereutectic pistons
  • Internal Front/ External Rear engine balance

Cylinder Heads:

  • BluePrint Aluminum Cylinder Heads - H8002K
  • 64cc chamber
  • 2.02" intake/1.60" exhaust valves
  • 195cc intake/75cc exhaust runners

Cam Specs:

  • Cam Type: Roller
  • .495 Intake .502 Exhaust
  • 220 Intake / 224 Exhaust duration
  • @ .050 - 114 degree lobe separation

Ignition Timing:

  • 32 Degrees Total at 3500 RPM

Also Includes:

  • Valve covers
  • Oil pan
  • Harmonic Balancer
  • Spark plugs and Wires
  • Timing cover
  • Aluminum intake
  • Waterneck and Thermostat
  • HEI distributor
  • EFI system
  • Dyno test results shipped with engine
  • Front Accessory Drive with Water Pump, A/C Compressor, Alternator, and
  • Power Steering Pump (Does not fit Corvette)

Warranty:

  • 30 month / 50,000 mile

Notes:


This engine will be dyno tested before it ships to you at no additional charge (others charge $500)!
Part #: BP3505CTFK

Description:

Dyno Tested Warranty
  • HP & Torque: 390 HP / 410 FT LBS
  • Compression Ratio: 9.2:1
  • Aluminum Heads
  • Hydraulic Roller Cam
  • Cast Iron Crankshaft
  • Hypereutectic Pistons

Block:

  • NEW BluePrint Cast Iron Block
  • Manufactured and Machined in the USA!
  • 4-Bolt Main
  • 4.000" Bore
  • 1-Piece Rear Main Seal
  • Mech fuel pump provision: Yes
  • Passenger Side Dipstick
  • Drilled and tapped for clutch linkage

Rotating Assembly:

  • Cast Iron Crankshaft
  • 3.480" Stroke
  • Forged 5.700" connecting rods
  • Hypereutectic pistons
  • Internal Front/ External Rear engine balance

Cylinder Heads:

  • BluePrint Aluminum Cylinder Heads - H8002K
  • 64cc chamber
  • 2.02" intake/1.60" exhaust valves
  • 195cc intake/75cc exhaust runners

Cam Specs:

  • Cam Type: Roller
  • .495 Intake .502 Exhaust
  • 220 Intake / 224 Exhaust duration
  • @ .050 - 114 degree lobe separation

Ignition Timing:

  • 32 Degrees Total at 3500 RPM

Also Includes:

  • Valve covers
  • Oil pan
  • Harmonic Balancer
  • Spark plugs and Wires
  • Timing cover
  • Aluminum intake
  • Waterneck and Thermostat
  • HEI distributor
  • EFI system
  • Dyno test results shipped with engine
  • Front Accessory Drive with Water Pump, A/C Compressor, Alternator, and
  • Power Steering Pump (Does not fit Corvette)

Warranty:

  • 30 month / 50,000 mile

Notes:


Customer Reviews

Based on 2 reviews Write a review

Your BluePrint engine was dyno tested with the parts and specifications listed below.  If you prefer to install a different part, your engine may not produce the horsepower recorded on your dyno sheet.



Part Number: BP3505CTFK

Fuel Delivery Type: Fuel Injected

Spark Plug: BPP7938 NGK 7938 BKR5E

Spark Plug Gap: .035"

Harmonic Balancer: Recommend BPP350 - Non Weighted, 8" diameter

Flexplate/Flywheel: Recommend Late 350 Weighted

Stall Converter: 2000-2400 rpm

Intake Manifold:  Dual plane, aluminum  BPP350VINT

Fuel Recommendation: 91 Octane

Timing (Initial/Total Advance): Initial timing - 10-16° and Total timing 32°

Firing Order: 1,8,4,3,6,5,7,2

Recommended Break in Oil : BPP710 (Click Here)

Recommended Service Oil : BPP10W30 (Click Here)

Recommended Oil Filter ; BPP51061 (Click Here)

Total Oil capacity with production oil pan, and Correct BPP51061 Filter : 5 Quarts



Click here to download a copy of the Installation Guide that came with your BluePrint engine.
