New Block Casting 350CI Cruiser Crate Engine | Deluxe Dressed Longblock | Aluminum Heads | Roller Cam | Fuel Injected
This engine will be dyno tested before it ships to you at no additional charge (others charge $500)!
Part #: BP350CTFD
Description:


- HP & Torque: 341 HP / 371 FT LBS
Compression Ratio: 9.2:1
Aluminum Heads
Hydraulic Roller Cam
Cast Iron Crankshaft
Hypereutectic Pistons
Block:
- NEW BluePrint Cast Iron Block
Manufactured and Machined in the USA!
4-Bolt Main
4.000" Bore
1-Piece Rear Main Seal
Mech fuel pump provision: Yes
Passenger Side Dipstick - Drilled and tapped for clutch linkage
Rotating Assembly:
-
Cast Iron Crankshaft
3.480" Stroke
Forged 5.700" connecting rods
Hypereutectic pistons
Internal Front/ External Rear engine balance
Cylinder Heads:
- BluePrint Aluminum Cylinder Heads - H8002K
64cc chamber
2.02" intake/1.60" exhaust valves
195cc intake/75cc exhaust runners
Cam Specs:
- Cam Type: Roller
.477 Intake .471 Exhaust
202 Intake / 212 Exhaust duration
@ .050 - 115 degree lobe separation
Ignition Timing:
- 32 Degrees Total at 3500 RPM
Also Includes:
- Valve covers
Oil pan
Timing cover - Harmonic Balancer
- Standard rotation long water pump
- Thermostat and Water neck
-
Aluminum intake
HEI distributor - Spark plugs and wires
EFI system
Dyno test results shipped with engine
Warranty:
- 30 month / 50,000 mile
This engine will be dyno tested before it ships to you at no additional charge (others charge $500)!
Part #: BP350CTFD
Description:


- HP & Torque: 341 HP / 371 FT LBS
Compression Ratio: 9.2:1
Aluminum Heads
Hydraulic Roller Cam
Cast Iron Crankshaft
Hypereutectic Pistons
Block:
- NEW BluePrint Cast Iron Block
Manufactured and Machined in the USA!
4-Bolt Main
4.000" Bore
1-Piece Rear Main Seal
Mech fuel pump provision: Yes
Passenger Side Dipstick - Drilled and tapped for clutch linkage
Rotating Assembly:
-
Cast Iron Crankshaft
3.480" Stroke
Forged 5.700" connecting rods
Hypereutectic pistons
Internal Front/ External Rear engine balance
Cylinder Heads:
- BluePrint Aluminum Cylinder Heads - H8002K
64cc chamber
2.02" intake/1.60" exhaust valves
195cc intake/75cc exhaust runners
Cam Specs:
- Cam Type: Roller
.477 Intake .471 Exhaust
202 Intake / 212 Exhaust duration
@ .050 - 115 degree lobe separation
Ignition Timing:
- 32 Degrees Total at 3500 RPM
Also Includes:
- Valve covers
Oil pan
Timing cover - Harmonic Balancer
- Standard rotation long water pump
- Thermostat and Water neck
-
Aluminum intake
HEI distributor - Spark plugs and wires
EFI system
Dyno test results shipped with engine
Warranty:
- 30 month / 50,000 mile
Customer Reviews
Your BluePrint engine was dyno tested with the parts and specifications listed below. If you prefer to install a different part, your engine may not produce the horsepower recorded on your dyno sheet.
Part Number: BP350CTFD
Fuel Delivery Type: Fuel Injected
Spark Plug: BPP7938 NGK 7938 BKR5E
Spark Plug Gap: .035"
Harmonic Balancer: Recommend BPP350 - Non Weighted, 8" diameter
Flexplate/Flywheel: Recommend Late 350 Weighted
Stall Converter: Stock
Intake Manifold: Dual plane, aluminum BPP350VINT
Fuel Recommendation: 87 Octane
Timing (Initial/Total Advance): Initial timing - 10-16° and Total timing 32°
Firing Order: 1,8,4,3,6,5,7,2
Recommended Break in Oil : BPP710 (Click Here)
Recommended Service Oil : BPP10W30 (Click Here)
Recommended Oil Filter ; BPP51061 (Click Here)
Total Oil capacity with production oil pan, and Correct BPP51061 Filter : 5 Quarts
Click here to download a copy of the Installation Guide that came with your BluePrint engine.
