Highlights:
- Horsepower and Torque: 872 Horsepower / 764 FT. LBS.
- Cylinder Heads: Gen III Apache Aluminum Cylinder Heads
- Compression Ratio: 10.48:1
- Pisons: Forged
Block:
- Engine Manufacturing and Machined in the USA!
- NEW “BGE” Hellcat Engine Block
- 4-Bolt Main
- 4.090" Bore
- 1-Piece Rear Main Seal
Rotating Assembly:
- Forged Steel Crank
- 4.050" Stroke
- 6.125" Connecting Rods
- Forged Pistons
- Internally Balanced Front and Rear
Cylinder Heads:
- Gen III Hemi Apache Aluminum Cylinder Heads
- 73cc Chamber
- 2.140" Intake / 1.650" Exhaust Valves
Cam Specs:
- Hydraulic Roller Cam
- .610 Intake / .611 Exhaust Lift
- 231 Intake / 255 Exhaust Duration
- @.050-113 Degree Lobe Separation
Ignition Timing:
- Controlled by ECU
Also Includes:
- Whipple 3.0L supercharger
- Supercharger Coolant Reservoir
- Hellcat Throttle Body
- Harmonic Balancer
- Muscle Car Style - Mid Sump Swap Oil Pan
- Spark plugs
- Coil
- Timing Cover
-
Valve Covers
- Water Pump
-
Holley Terminator ECU Controller Kit and Wiring Harness
Notes:
- Features 2013+ 58X reluctor wheel
- 2009+ crankshaft spacing
- 2009+ car timing cover
- VVT locked out
- MDS – eliminated
BETTER THAN THE REST.
The satisfaction of our customers is our highest priority at BluePrint Engines. We use quality components to balance your engine's rotating assembly within two grams of spec. We dyno test your crate engine and certify that it's ready to deliver horsepower and torque.
We give your BluePrint engine the industry's best-in-class warranty for 30-months / 50,000 miles — with the extra confidence only BluePrint can provide. Our warranty applies to individual or professional installations and is fully transferable.
For a detailed overview of our warranty, click here.
IT ALL COMES DOWN TO RESULTS.
We make sure we hit our target horsepower and proper torque with every crate engine. We use an advanced computerized balancer to get our rotating assemblies within two grams, ensuring silky smooth power over the entire RPM range. That's precisely why our engines sound and run better than our competitors.
BRAGGING RIGHTS INCLUDED!
A comprehensive, dyno-generated printout showing these critical specs will accompany your delivered engine. No more guessing or wondering what your installed engine's real-world peak horsepower and torque ratings actually are. Any doubters in the crowd? Simply flash 'em your dyno results!
This engine will be dyno tested before it ships to you at no additional charge (others charge $500)!
