540 CI ProSeries Stroker Crate Engine | Big Block GM Style | BBC | Longblock

$10,299.00

This engine will be dyno tested before it ships to you at no additional charge (others charge $500)!

Part Number: PS5401CT

  • Dyno Tested Warranty
  • HP & Torque: 670 HP / 660 FT LBS
    Compression Ratio: 10.0:1
    Aluminum Heads
    Hydraulic Roller Cam
    Forged Crank
    Forged Pistons

Block:

  • NEW BluePrint Cast Iron Block
    Manufactured and Machined in the USA!
    4-Bolt Main
    4.500" Bore
    1-Piece Rear Main Seal
    Mech fuel pump provision: Yes
    Standard Deck

Rotating Assembly:

  • New BluePrint Forged Crankshaft
    4.250" Stroke
    Forged H-beam 6.385" connecting rods
    Forged Pistons
    Internal

Cylinder Heads:

  • BluePrint Aluminum Cylinder Heads -PS8013
  • 119cc chamber
  • 2.30" intake/1.88" exhaust valves
  • 316cc intake/124cc exhaust runners
  • Cylinder heads feature a .300 in. raised exhaust port vs an OEM casting.
  • Must verify header/exhaust clearance

Cam Specs:

  • Cam Type: Roller
    .647 Intake .647 Exhaust
    248 Intake / 254 Exhaust duration
    @ .050 - 112 degree lobe separation

Also Includes:

  • Valve covers, oil pan and timing cover
    Harmonic balancer
    Dyno test results shipped with engine

Warranty:

 30 month / 50,000 mile



Notes:

  • New BluePrint block manufactured and machined in the USA.
  • Not for EGR
  • Cylinder heads feature a .300 in. raised exhaust port vs an OEM casting
  • Must verify header/exhaust clearance



      Yellow Exclamation Triangle WARNING: Cancer and Reproductive Harm-
      www.P65Warnings.ca.gov

      This engine will be dyno tested before it ships to you at no additional charge (others charge $500)!

      Part Number: PS5401CT

      • Dyno Tested Warranty
      • HP & Torque: 670 HP / 660 FT LBS
        Compression Ratio: 10.0:1
        Aluminum Heads
        Hydraulic Roller Cam
        Forged Crank
        Forged Pistons

      Block:

      • NEW BluePrint Cast Iron Block
        Manufactured and Machined in the USA!
        4-Bolt Main
        4.500" Bore
        1-Piece Rear Main Seal
        Mech fuel pump provision: Yes
        Standard Deck

      Rotating Assembly:

      • New BluePrint Forged Crankshaft
        4.250" Stroke
        Forged H-beam 6.385" connecting rods
        Forged Pistons
        Internal

      Cylinder Heads:

      • BluePrint Aluminum Cylinder Heads -PS8013
      • 119cc chamber
      • 2.30" intake/1.88" exhaust valves
      • 316cc intake/124cc exhaust runners
      • Cylinder heads feature a .300 in. raised exhaust port vs an OEM casting.
      • Must verify header/exhaust clearance

      Cam Specs:

      • Cam Type: Roller
        .647 Intake .647 Exhaust
        248 Intake / 254 Exhaust duration
        @ .050 - 112 degree lobe separation

      Also Includes:

      • Valve covers, oil pan and timing cover
        Harmonic balancer
        Dyno test results shipped with engine

      Warranty:

       30 month / 50,000 mile



      Notes:

      • New BluePrint block manufactured and machined in the USA.
      • Not for EGR
      • Cylinder heads feature a .300 in. raised exhaust port vs an OEM casting
      • Must verify header/exhaust clearance



          Yellow Exclamation Triangle WARNING: Cancer and Reproductive Harm-
          www.P65Warnings.ca.gov

          Your BluePrint engine was dyno tested with the parts and specifications listed below.  If you prefer to install a different part, your engine may not produce the horsepower recorded on your dyno sheet.



          Part Number: PS5401CT

          Fuel Delivery Type: Carbureted, 850cfm recommended

          Spark Plug: BPP7938 NGK 7938 BKR5E

          Spark Plug Gap: .035"

          Harmonic Balancer: Non-Weighted

          Flexplate/Flywheel: Non-Weighted

          Stall Converter: 2200+

          Intake Manifold: Single Plane recommended

          Fuel Recommendation: 91 Octane

          Timing (Initial/Total Advance): Initial timing - 10-16° and Total timing 32-34°

          Firing Order: 1,8,4,3,6,5,7,2

          Recommended Break in Oil : BPP710 (Click Here)

          Recommended Service Oil : BPP10W30 (Click Here)

          Recommended Oil Filter ; BPP51061 (Click Here)

          Total Oil capacity with production oil pan, and Correct BPP51061 Filter : 8 Quarts

          Notes: New BluePrint block manufactured and machined in the USA,

          Click here to download a copy of the Installation Guide that came with your BluePrint engine.
