New 350CI Crate Engine | Base Dressed Longblock | Aluminum Heads | Roller Cam | Fuel Injection
Part #: BP3505CTF
Description:
- HP & Torque: 390 HP / 410 FT LBS
- Compression Ratio: 9.2:1
- Aluminum Heads
- Hydraulic Roller Cam
- Cast Iron Crankshaft
- Hypereutectic Pistons
Block:
- NEW BluePrint Cast Iron Block
- Manufactured and Machined in the USA!
- 4-Bolt Main
- 4.000" Bore
- 1-Piece Rear Main Seal
- Mech fuel pump provision: Yes
- Passenger Side Dipstick
- Drilled and tapped for clutch linkage
Rotating Assembly:
- Cast Iron Crankshaft
- 3.480" Stroke
- Forged 5.700" connecting rods
- Hypereutectic pistons
- Internal Front/ External Rear engine balance
Cylinder Heads:
- BluePrint Aluminum Cylinder Heads - H8002K
- 64cc chamber
- 2.02" intake/1.60" exhaust valves
- 195cc intake/75cc exhaust runners
Cam Specs:
- Cam Type: Roller
- .495 Intake .502 Exhaust
- 220 Intake / 224 Exhaust duration
- @ .050 - 114 degree lobe separation
Ignition Timing:
- 32 Degrees Total at 3500 RPM
Also Includes:
- Valve covers
- Oil pan
- Timing cover
- Aluminum intake
- HEI distributor
- EFI system
- Dyno test results shipped with engine
Warranty:
- 30 month / 50,000 mile
Notes:
- The performance aluminum cylinder heads on this engine feature a .500 raised port vs OEM.
Part #: BP3505CTF
Description:
- HP & Torque: 390 HP / 410 FT LBS
- Compression Ratio: 9.2:1
- Aluminum Heads
- Hydraulic Roller Cam
- Cast Iron Crankshaft
- Hypereutectic Pistons
Block:
- NEW BluePrint Cast Iron Block
- Manufactured and Machined in the USA!
- 4-Bolt Main
- 4.000" Bore
- 1-Piece Rear Main Seal
- Mech fuel pump provision: Yes
- Passenger Side Dipstick
- Drilled and tapped for clutch linkage
Rotating Assembly:
- Cast Iron Crankshaft
- 3.480" Stroke
- Forged 5.700" connecting rods
- Hypereutectic pistons
- Internal Front/ External Rear engine balance
Cylinder Heads:
- BluePrint Aluminum Cylinder Heads - H8002K
- 64cc chamber
- 2.02" intake/1.60" exhaust valves
- 195cc intake/75cc exhaust runners
Cam Specs:
- Cam Type: Roller
- .495 Intake .502 Exhaust
- 220 Intake / 224 Exhaust duration
- @ .050 - 114 degree lobe separation
Ignition Timing:
- 32 Degrees Total at 3500 RPM
Also Includes:
- Valve covers
- Oil pan
- Timing cover
- Aluminum intake
- HEI distributor
- EFI system
- Dyno test results shipped with engine
Warranty:
- 30 month / 50,000 mile
Notes:
- The performance aluminum cylinder heads on this engine feature a .500 raised port vs OEM.
Customer Reviews
Your BluePrint engine was dyno tested with the parts and specifications listed below. If you prefer to install a different part, your engine may not produce the horsepower recorded on your dyno sheet.
Part Number: BP3505CT
Fuel Delivery Type: Fuel Injected
Spark Plug: BPP7938 NGK 7938 BKR5E
Spark Plug Gap: .035"
Harmonic Balancer: Not included, recommend BPP350 - Non Weighted, 8" diameter
Flexplate/Flywheel: Not included, recommend Late 350 Weighted
Stall Converter: 2000-2400 rpm
Intake Manifold: Dual plane, aluminum BPP350VINT
Fuel Recommendation: 91 Octane
Timing (Initial/Total Advance): Initial timing - 10-16° and Total timing 32°
Firing Order: 1,8,4,3,6,5,7,2
Recommended Break in Oil : BPP710 (Click Here)
Recommended Service Oil : BPP10W30 (Click Here)
Recommended Oil Filter ; BPP51061 (Click Here)
Total Oil capacity with production oil pan, and Correct BPP51061 Filter : 5 Quarts
Header Partners: HUSLER 770-664-8880 Sanderson 650-583-4590 Lemons 805-239-8998
Click here for more Header Info.
Click here to download a copy of the Installation Guide that came with your BluePrint engine.
