SKU: BP3505CTCD

GM Small Block Compatible 350 c.i. Engine - 390 Horsepower - Deluxe Dressed - Carbureted

SKU: BP3505CTCD

Horsepower & Torque: 390 Horsepower / 410 FT. LBS. Torque

Cylinder Heads: BluePrint Engines Aluminum Cylinder Heads

Compression Ratio: 9.2:1

Camshaft: Hydraulic Roller Cam - .495 Intake / .502 Exhaust Lift and 220 Intake / 224 Exhaust Duration @ .050-114° LSA

Pistons: Hypereutectic

Crankshaft: Cast Crank - 3.480" Stroke and 5.700" Rods

Fuel Recommendation: 87+ Octane

Regular price $6,299.00
/
  • Secure payments
  • Financing available at checkout with Affirm

Description:

  • Horsepower & Torque: 390 Horsepower / 410 FT. LBS. Torque
  • Compression Ratio: 9.2:1
  • Aluminum Heads
  • Hydraulic Roller Cam
  • Cast Crankshaft
  • Hypereutectic Pistons

Block:

  • NEW BluePrint Cast Iron Block
  • Manufactured and Machined in the USA!
  • 4-Bolt Main
  • 4.000" Bore
  • 1-Piece Rear Main Seal
  • Mech Fuel Pump Provision: Yes
  • Passenger Side Dipstick
  • Drilled and Tapped for Clutch Linkage

Rotating Assembly:

  • Cast Crankshaft
  • 3.480" Stroke
  • Forged 5.700" Connecting Rods
  • Hypereutectic Pistons
  • Internally Balanced Front - Externally Balanced Rear

Cylinder Heads:

  • BluePrint Aluminum Cylinder Heads - H8002K
  • 64cc Chamber
  • 2.02" Intake / 1.60" Exhaust Valves
  • 195cc Intake / 75cc Exhaust Runners

Cam Specs:

  • Hydraulic Roller
  • .495 Intake / .502 Exhaust Lift
  • 220 Intake / 224 Exhaust Duration
  • @ .050-114 Degree Lobe Separation

Ignition Timing:

  • 32 Degrees Total at 3500 RPM

Also Includes:

  • Holley 670 CFM Brawler Carburetor - BPP67256670
  • Standard Rotation Long Style Water Pump
  • Thermostat and Thermostat Housing
  • Valve Covers
  • Harmonic Balancer
  • Spark Plugs
  • Spark Plug Wires
  • Mechanical Fuel Pump - BPP61073
  • Rear Sump Oil Pan
  • Timing Cover
  • Aluminum Intake
  • HEI Distributor

Recommended Break in Oil: BPP710 (Click Here)

Recommended Service Oil: BPP10W30 (Click Here)

Recommended Oil Filter: BPP51061 (Click Here)

Notes:

  • The performance aluminum cylinder heads on this engine feature a .500 raised port vs OEM.

    Your BluePrint engine was dyno tested with the parts and specifications listed below. If you prefer to install a different part, your engine may not produce the horsepower recorded on your dyno sheet.

    Part Number: BP3505CTCD

    Fuel Delivery Type: Carbureted

    Spark Plug: BPP7938 NGK 7938 BKR5E (.750 inch reach, 14mm thread, 5/8 hex, plug)

    Spark Plug Gap: .035"

    Harmonic Balancer: Recommend BPP350 - Non-Weighted, 8" Diameter

    Flexplate/Flywheel: Recommend Late 350 Weighted BPP871006

    Stall Converter: 2000-2400 rpm

    Intake Manifold:  Dual Plane, Satin Aluminum BPP350VINT

    Fuel Recommendation: 87 Octane Approved

    Timing (Initial/Total Advance): Initial Timing 10-16° and Total Timing 32°

    Firing Order: 1,8,4,3,6,5,7,2

    Recommended Break in Oil: BPP710 (Click Here)

    Recommended Service Oil: BPP10W30 (Click Here)

    Recommended Oil Filter: BPP51061 (Click Here)

    Total Oil Capacity with Production Oil Pan, and Correct: BPP51061 Filter - 5 Quarts

    Header Partners:
    Click here for our Header Partners and recommendations.

    Click here to download a copy of the Installation Guide that came with your BluePrint engine.

    BETTER THAN THE REST.

    At BluePrint Engines, customer satisfaction is our highest priority. Every engine is built using high-quality components, with each rotating assembly balanced to within two grams of specification. Before shipment, every crate engine is dyno tested and certified to ensure it is ready to deliver the horsepower and torque you expect.

    To stand behind that level of quality, BluePrint Engines offers industry-leading warranty coverage, providing confidence and peace of mind whether the engine is installed by an individual or a professional installer. Our standard warranty is fully transferable, adding long-term value and reassurance for our customers.

    Warranty Coverage Details:

    • BluePrint Engines (including Builder Series)- Standard Warranty 30 months or 50,000 miles (parts and labor)*
    • BluePrint Engines Extended Warranty- 48 months or unlimited miles (parts and labor)*
    • Race / Motorsports Engines -No warranty
    • Marine Engines- 12 months (parts and labor)
    • Short Blocks-12 months (parts only)
    • Bare Blocks- 6-Month Unaltered
    • International Sales- Warranty coverage is handled by the in-country distributor

    *Applies to eligible engine part numbers beginning with “B” or “P.” Warranty coverage is subject to terms and conditions. Proper installation and maintenance are required.

    Please refer to full warranty documentation for complete details click here.

    IT ALL COMES DOWN TO RESULTS.

    We make sure we hit our target horsepower and proper torque with every crate engine. We use an advanced computerized balancer to get our rotating assemblies within two grams, ensuring silky smooth power over the entire RPM range. That's precisely why our engines sound and run better than our competitors.

    BRAGGING RIGHTS INCLUDED!

    A comprehensive, dyno-generated printout showing these critical specs will accompany your delivered engine. No more guessing or wondering what your installed engine's real-world peak horsepower and torque ratings actually are. Any doubters in the crowd? Simply flash 'em your dyno results!

    This engine will be dyno tested before it ships to you at no additional charge (others charge $500)!
