SKU: B426SCTK4L8

Chrysler Hemi Compatible 426 c.i. Engine and 4L80E Automatic Transmission - 872 Horsepower - Standard Edition Builder Series - Polished Pulley Kit - Supercharged

SKU: B426SCTK4L8

Horsepower & Torque: 872 Horsepower / 764 FT. LBS. Torque

Cylinder Heads: Gen III Hemi Apache Aluminum Cylinder Heads

Compression Ratio: 10.48:1

Camshaft: Hydraulic Roller Cam - .610 Intake / .611 Exhaust Lift and 231 Intake / 255 Exhaust Duration @.050-113° LSA

Pistons: Forged

Crankshaft: Forged Steel Crank - 4.050" Stroke and Forged 6.125" Connecting Rods

Fuel Recommendation: 91+ Octane

/
  • Secure payments
  • Financing available at checkout with Affirm

Overview:

This BluePrint Engines Gen III HEMI crate engine paired with a complete 4L80E four-speed automatic transmission is a turnkey, high-performance powerhouse, producing an incredible 872 horsepower and 764 ft-lbs. of torque with a pump-gas-friendly 10.48:1 compression ratio. Built with premium internals—including a forged crank, forged pistons, and a hydraulic roller cam—and topped with Gen III HEMI Apache aluminum cylinder heads, this engine is force-fed by a Whipple 3.0L supercharger and Hellcat throttle body, backed by a dedicated supercharger coolant reservoir for consistent performance. Engine management is handled by a Holley Terminator ECU controller kit and wiring harness, providing precise control over fuel injection and ignition. Key components like spark plugs, coils, timing cover, valve covers, harmonic balancer, and a muscle car-style mid-sump oil pan make this engine swap-ready. The polished front accessory drive system includes a high-flow water pump, Type II power steering pump with remote reservoir, 140-amp 1-wire alternator, and a 7B10 peanut-style A/C compressor, blending function and show-quality looks. With the strength and overdrive capability of the 4L80E transmission, this package is ideal for high-powered street machines demanding modern reliability and supercharged performance.

Description

  • Horsepower & Torque: 872 Horsepower / 764 ft. lbs. Torque
  • Compression Ratio: 10.48:1
  • Gen III Hemi Apache Aluminum Cylinder Heads
  • BluePrint Engines Hydraulic Roller Cam
  • BluePrint Engines Forged Crank
  • BluePrint Engines Forged Pistons

Block:

  • Engine Manufactured and Machined in the USA!
  • NEW “BGE” Hellcat Engine Block
  • 4-Bolt Main
  • 4.090" Bore
  • 1-Piece Rear Main Sea

Rotating Assembly:

  • Forged Steel Crank
  • 4.050" Stroke
  • 6.125" Connecting Rods
  • Forged Pistons
  • Internally Balanced Front and Rear

Cylinder Heads:

  • Gen III Hemi Apache Aluminum Cylinder Heads
  • 73cc Chamber
  • 2.140" Intake / 1.650" Exhaust Valves

Cam Specs:

  • Hydraulic Roller Cam
  • .614 Intake / .614 Exhaust Lift
  • 231 Intake / 255 Exhaust Duration
  • @.050-115.5 Degree Lobe Separation

Ignition Timing:

  • Controlled by ECU

Also Includes:

  • Whipple 3.0L supercharger
  • Supercharger Coolant Reservoir
  • Hellcat Throttle Body
  • Harmonic Balancer
  • Muscle Car Style - Mid Sump Swap Oil Pan
  • Spark plugs
  • Coil
  • Timing Cover
  • Valve Covers
  • Holley Terminator ECU Controller Kit and Wiring Harness
  • Polished Front Accessory Drive -
    • Water Pump
    • Type II Power Steering Pump
    • Remote Power Steering Pump Reservoir
    • 140amp 1-wire Alternator
    • 7B10 Peanut Style Air Conditioning Compressor

Assembled with Complete 4L80E Four Speed Automatic Transmission Package:

  • 4L80E Complete Package
  • Electronic Transmission Controller Included
  • 3000+ Stall Torque Converter
  • Flex Plate
  • Starter

4L80E Gear Ratios:

  • 1: 2.482
  • 2: 1.482
  • 3: 1.00
  • 4: 0.750
  • R: 2.077

Notes:

  • Features 2013+ 58X reluctor wheel
  • 2009+ crankshaft spacing
  • 2009+ car timing cover
  • VVT locked out
  • MDS – eliminated

Your BluePrint engine was dyno tested with the parts and specifications listed below. If you prefer to install a different part, your engine may not produce the horsepower recorded on your dyno sheet.

Fuel Delivery Type: Whipple 3.0L supercharger

Spark Plug: NGK 5107

Spark Plug Gap: .025"

Harmonic Balancer: Non-Weighted

Flexplate/ Flywheel: Non-Weighted

Stall Converter: 2500+

Intake Manifold: Supercharger

Fuel Recommendation: 91+ Octane Approved

Timing: Controlled by ECU

Firing Order: 1-8-4-3-6-5-7-2

Recommended Break-in Oil: BPP710

Recommended Service Oil: BPP10W30

Recommended Oil Filter: BPPB160

Total Oil Capacity with Production Oil Pan: 6 QT.

Header Partners: Click here for our Header Partners and recommendations

Click here to download a copy of the Installation Guide that came with your BluePrint engine.

BETTER THAN THE REST.

The satisfaction of our customers is our highest priority at BluePrint Engines. We use quality components to balance your engine's rotating assembly within two grams of spec. We dyno test your crate engine and certify that it's ready to deliver horsepower and torque.

We give your BluePrint engine the industry's best-in-class warranty for 30-months / 50,000 miles — with the extra confidence only BluePrint can provide. Our warranty applies to individual or professional installations and is fully transferable.

For a detailed overview of our warranty, click here.

IT ALL COMES DOWN TO RESULTS.

We make sure we hit our target horsepower and proper torque with every crate engine. We use an advanced computerized balancer to get our rotating assemblies within two grams, ensuring silky smooth power over the entire RPM range. That's precisely why our engines sound and run better than our competitors.

BRAGGING RIGHTS INCLUDED!

A comprehensive, dyno-generated printout showing these critical specs will accompany your delivered engine. No more guessing or wondering what your installed engine's real-world peak horsepower and torque ratings actually are. Any doubters in the crowd? Simply flash 'em your dyno results!

This engine will be dyno tested before it ships to you at no additional charge (others charge $500)!
