Name: BluePrint Motorsports GM Big Block Compatible 632 c.i. Pro Series Engine - 815 Horsepower - Blackout Reaper Edition Deluxe Dressed - Black Pulley Kit - Carbureted
Brand: BluePrint Engines
SKU: PS6320CTCKBX
Price: 19499.0 USD
Availability: InStock

BluePrint Motorsports GM Big Block Compatible 632 c.i. Pro Series Engine - 815 Horsepower - Blackout Reaper Edition Deluxe Dressed - Black Pulley Kit - Carbureted

Horsepower & Torque: 815 Horsepower / 800 ft. lbs. Torque

Cylinder Heads: BluePrint Engines Aluminum Cylinder Heads

Compression Ratio: 11:1

Camshaft: Hydraulic Roller Cam - .698 Intake / .698 Exhaust Lift and 272 Intake / 282 Exhaust Duration @ .050 - 110° LSA

Pistons: Forged

Crankshaft: Steel Crank - 4.750" Stroke and Forged 6.635" Rods

Requires Race Fuel of 100+ Octane

Price

Secure payments

Financing available at checkout with Affirm

BluePrint Motorsports GM Big Block Compatible 632 c.i. Pro Series Engine - 815 Horsepower - Blackout Reaper Edition Deluxe Dressed - Black Pulley Kit - Carbureted

PS6320CTCKBX

Blackout Edition

Overview:

Meet the monster that’s powerful enough to dominate the track yet tame enough to rule the streets. Packing a jaw-dropping 815 horsepower and 800 ft-lbs of torque, this 632 cubic inch Pro Series BBC compatible engine is the ultimate blend of raw performance and street-friendly manners. It features a streetable hydraulic roller camshaft, forged pistons, H-beam rods, and a steel crankshaft all anchored in a BluePrint high-strength cast iron block, proudly manufactured and machined in the USA. Topped off with BluePrint aluminum cylinder heads, this is the heart your street beast deserves.

Description:

Horsepower & Torque: 815 Horsepower / 775 ft. lbs. Torque
Compression Ratio: 11.0:1
BluePrint Engines Aluminum Heads
BluePrint Engines Hydraulic Roller Cam
BluePrint Engines Forged Crank
BluePrint Engines Forged Pistons

Block:

BluePrint Engines High Strength Cast Iron Block
Manufactured and Machined in the USA!
Tall Deck (Cylinder Deck is Approx .400 taller / Wider than OEM Block)
Mech Fuel Pump Provision: Yes
1-Piece Rear Main Seal
4-Bolt Main
4.600" Bore

Rotating Assembly:

BluePrint Forged Crankshaft
4.750" Stroke
Forged H-beam 6.635" Connecting Rods
Forged Pistons
Internally Balanced Front and Rear

Cylinder Heads:

BluePrint Aluminum Cylinder Heads - PS8012
119cc Chamber
2.30" Intake / 1.88" Exhaust Valves
358cc Intake / 125cc Exhaust Runners
Cylinder Heads Feature a .300 in. Raised Exhaust Port vs an OEM Casting.

Cam Specs:

Hydraulic Roller
.698 Intake / .698 Exhaust Lift
272 Intake / 282 Exhaust Duration
@.050-110 Degree Lobe Separation

Also Includes:

Front Accessory Drive with Alternator, Power Steering Pump, A/C Compressor, and Water Pump
Holley GEN III Ultra Dominator Carburetor
Pro Billet Distributor - BPP3503BK
Harmonic Balancer - BPP454I
Spark Plugs - BPP7938
Spark Plug Wires
Intake Manifold
Timing Cover
Valve Covers
Oil Pan

Notes:

This engine is built and designed to run on 92 octane pump gas for street use only. For racing or extended wide-open throttle use, race fuel (100+ octane) is required.
BluePrint Motorsports engines are built for maximum performance and are intended for extreme duty applications. Because of the high-stress nature of their use, these engines are sold without any warranty, expressed, or implied.

Your BluePrint engine was dyno tested with the parts and specifications listed below. If you prefer to install a different part, your engine may not produce the horsepower recorded on your dyno sheet.

Part Number: PS6320CTCKBX

Fuel Delivery Type: Carbureted 1250CFM

Spark Plug: BPP7938 NGK 7938 BKR5E (.750-inch reach, 14mm thread, 5/8 hex, plug)

Spark Plug Gap: .035"

Harmonic Balancer: Non-Weighted

Flexplate/Flywheel: Non-Weighted

Stall Converter: Customer should match engine output and car setup to find best converter.

Intake Manifold: Single Plane, Satin Aluminum

Fuel Recommendation: Requires Race Fuel of 100+ Octane

Timing (Initial/Total Advance): Initial timing - 10-16° and Total timing 32-34°. If using a dominator style carb, initial timing 16-20 and total timing of 32-34 by 2500 RPM.

Firing Order: 1,8,4,3,6,5,7,2

Recommended Break in Oil: BPP710 (Click Here)

Recommended Service Oil: BPP10W30 (Click Here)

Recommended Oil Filter: BPP51061 (Click Here)

Total Oil capacity with production oil pan, and Filter: 8 Quarts

Click here to download a copy of the Installation Guide that came with your BluePrint engine.

Header Partners:
Click here for our Header Partners and recommendations.

BETTER THAN THE REST.

The satisfaction of our customers is our highest priority at BluePrint Engines. We use quality components to balance your engine's rotating assembly within two grams of spec. We dyno test your crate engine and certify that it's ready to deliver horsepower and torque.

We give your BluePrint engine the industry's best-in-class warranty for 30-months / 50,000 miles — with the extra confidence only BluePrint can provide. Our warranty applies to individual or professional installations and is fully transferable.

For a detailed overview of our warranty, click here.

IT ALL COMES DOWN TO RESULTS.

We make sure we hit our target horsepower and proper torque with every crate engine. We use an advanced computerized balancer to get our rotating assemblies within two grams, ensuring silky smooth power over the entire RPM range. That's precisely why our engines sound and run better than our competitors.

BRAGGING RIGHTS INCLUDED!

A comprehensive, dyno-generated printout showing these critical specs will accompany your delivered engine. No more guessing or wondering what your installed engine's real-world peak horsepower and torque ratings actually are. Any doubters in the crowd? Simply flash 'em your dyno results!

This engine will be dyno tested before it ships to you at no additional charge (others charge $500)!
